    echarts在react中的引入使用(俩种方法)

    技术 383 2021-01-29 14:56

    一.第一步 先看看你的echarts版本。

    小于5.0版本的可以使用以下方法:

    先安装:

    npm i echarts@4.0.4 --save

    npm i echarts-for-react --save

    1.原始echarts

    导入

    import React from 'react'
    // 引入 ECharts 主模块
    import echarts from 'echarts/lib/echarts'
    // 引入饼图
    import 'echarts/lib/chart/bar'
    // 引入提示框和标题组件
    import 'echarts/lib/component/tooltip';
    import 'echarts/lib/component/title';
    import 'echarts/lib/component/legend';
    import 'echarts/lib/component/markPoint';


    实例化echarts

    componentDidMount() {
            // 基于准备好的dom,初始化echarts实例
            var myChart = echarts.init(document.getElementById('main'));
            // 绘制图表
            myChart.setOption({
                title: { text: 'ECharts 入门示例' },
                tooltip: {},
                xAxis: {
                    data: ["衬衫", "羊毛衫", "雪纺衫", "裤子", "高跟鞋", "袜子"]
                },
                yAxis: {},
                series: [{
                    name: '销量',
                    type: 'bar',
                    data: [5, 20, 36, 10, 10, 20]
                }]
            });
        }


    使用

    render() {
            return (
                <div id="main" style={{ width: 400, height: 400 }}></div>
            );
    }


    2.echarts-for-react

    import React, { PureComponent } from "react";
    import ReactEcharts from "echarts-for-react";
    export default class Simple extends PureComponent {
      getOption = () => {
        return {
          title: {
            text: "堆叠区域图",
          },
          tooltip: {
            trigger: "axis",
          },
          legend: {
            data: ["邮件营销", "联盟广告", "视频广告"],
          },
          toolbox: {
            feature: {
              saveAsImage: {},
            },
          },
          grid: {
            left: "3%",
            right: "4%",
            bottom: "3%",
            containLabel: true,
          },
          xAxis: [
            {
              type: "category",
              boundaryGap: false,
              data: ["周一", "周二", "周三", "周四", "周五", "周六", "周日"],
            },
          ],
          yAxis: [
            {
              type: "value",
            },
          ],
          series: [
            {
              name: "邮件营销",
              type: "line",
              stack: "总量",
              areaStyle: { normal: {} },
              data: [120, 132, 101, 134, 90, 230, 210],
            },
            {
              name: "联盟广告",
              type: "line",
              stack: "总量",
              areaStyle: { normal: {} },
              data: [220, 182, 191, 234, 290, 330, 310],
            },
            {
              name: "视频广告",
              type: "line",
              stack: "总量",
              areaStyle: { normal: {} },
              data: [150, 232, 201, 154, 190, 330, 410],
            },
          ],
        };
      };
      render() {
        let code =
          "<ReactEcharts \n" +
          "  option={this.getOption()} \n" +
          "  style={{height: '350px', width: '100%'}}  \n" +
          "  className='react_for_echarts' />";
        return (
          <div className="examples">
            <div className="parent">
              <label>
                {" "}
                render a Simple echart With <strong>option and height</strong>:{" "}
              </label>
              <ReactEcharts
                option={this.getOption()}
                style={{ height: "350px", width: "100%" }}
                className="react_for_echarts"
              />
              <label> code below: </label>
              <pre>
                <code>{code}</code>
              </pre>
            </div>
          </div>
        );
      }
    }



    5.0以上的暂时只能使用原始的e-charts引入。

    npm i echarts --save

    import React, { Component } from "react";
    // 注意这里 跟4.0相比 只是这里使用了require,使用import直接报错..
    const echarts = require("echarts");
    class Charts extends Component {
      constructor(props) {
        super(props);
        this.state = {
          option: {
            title: {
              text: "ECharts 入门示例",
            },
            tooltip: {},
            legend: {
              data: ["销量"],
            },
            xAxis: {
              data: ["衬衫", "羊毛衫", "雪纺衫", "裤子", "高跟鞋", "袜子"],
            },
            yAxis: {},
            series: [
              {
                name: "销量",
                type: "bar",
                data: [5, 20, 36, 10, 10, 20],
              },
            ],
          },
        };
      }
      componentDidMount() {
        // 基于准备好的dom,初始化echarts实例
        const MyChart = echarts.init(document.getElementById("main")); // 绘制图表
        let option = {
          title: {
            text: "ECharts 入门示例",
          },
          tooltip: {},
          legend: {
            data: ["销量"],
          },
          xAxis: {
            data: ["衬衫", "羊毛衫", "雪纺衫", "裤子", "高跟鞋", "袜子"],
          },
          yAxis: {},
          series: [
            {
              name: "销量",
              type: "bar",
              data: [5, 20, 36, 10, 10, 20],
            },
          ],
        };
        MyChart.setOption(option);
      }
      render() {
        return (
          <div>
                <div id="main" style={{ width: 400, height: 400 }}></div>
          </div>
        );
      }
    }

    export default Charts;



    另外附上E-charts的全部的配置

    theme = {
        // 全图默认背景
        // backgroundColor: 'rgba(0,0,0,0)',

        // 默认色板
        color: ['#ff7f50','#87cefa','#da70d6','#32cd32','#6495ed',
                '#ff69b4','#ba55d3','#cd5c5c','#ffa500','#40e0d0',
                '#1e90ff','#ff6347','#7b68ee','#00fa9a','#ffd700',
                '#6699FF','#ff6666','#3cb371','#b8860b','#30e0e0'],

        // 图表标题
        title: {
            x: 'left',                 // 水平安放位置,默认为左对齐,可选为:
                                       // 'center' ¦ 'left' ¦ 'right'
                                       // ¦ {number}(x坐标,单位px)
            y: 'top',                  // 垂直安放位置,默认为全图顶端,可选为:
                                       // 'top' ¦ 'bottom' ¦ 'center'
                                       // ¦ {number}(y坐标,单位px)
            //textAlign: null          // 水平对齐方式,默认根据x设置自动调整
            backgroundColor: 'rgba(0,0,0,0)',
            borderColor: '#ccc',       // 标题边框颜色
            borderWidth: 0,            // 标题边框线宽,单位px,默认为0(无边框)
            padding: 5,                // 标题内边距,单位px,默认各方向内边距为5,
                                       // 接受数组分别设定上右下左边距,同css
            itemGap: 10,               // 主副标题纵向间隔,单位px,默认为10,
            textStyle: {
                fontSize: 18,
                fontWeight: 'bolder',
                color: '#333'          // 主标题文字颜色
            },
            subtextStyle: {
                color: '#aaa'          // 副标题文字颜色
            }
        },

        // 图例
        legend: {
            orient: 'horizontal',      // 布局方式,默认为水平布局,可选为:
                                       // 'horizontal' ¦ 'vertical'
            x: 'center',               // 水平安放位置,默认为全图居中,可选为:
                                       // 'center' ¦ 'left' ¦ 'right'

                                       // ¦ {number}(x坐标,单位px)
            y: 'top',                  // 垂直安放位置,默认为全图顶端,可选为:
                                       // 'top' ¦ 'bottom' ¦ 'center'
                                       // ¦ {number}(y坐标,单位px)
            //也可以不使用x、y,使用left,right,top,bottom:20或'20%'为值的属性表示,
            //涉及到x、y的地方都可以使用此方法尝试
            backgroundColor: 'rgba(0,0,0,0)',
            borderColor: '#ccc',       // 图例边框颜色
            borderWidth: 0,            // 图例边框线宽,单位px,默认为0(无边框)
            padding: 5,                // 图例内边距,单位px,默认各方向内边距为5,
                                       // 接受数组分别设定上右下左边距,同css
            itemGap: 10,               // 各个item之间的间隔,单位px,默认为10,
                                       // 横向布局时为水平间隔,纵向布局时为纵向间隔
            itemWidth: 20,             // 图例图形宽度
            itemHeight: 14,            // 图例图形高度
            textStyle: {
                color: '#333'          // 图例文字颜色
            }
        },

        // 值域
        dataRange: {
            orient: 'vertical',        // 布局方式,默认为垂直布局,可选为:
                                       // 'horizontal' ¦ 'vertical'
            x: 'left',                 // 水平安放位置,默认为全图左对齐,可选为:
                                       // 'center' ¦ 'left' ¦ 'right'
                                       // ¦ {number}(x坐标,单位px)
            y: 'bottom',               // 垂直安放位置,默认为全图底部,可选为:
                                       // 'top' ¦ 'bottom' ¦ 'center'
                                       // ¦ {number}(y坐标,单位px)
            backgroundColor: 'rgba(0,0,0,0)',
            borderColor: '#ccc',       // 值域边框颜色
            borderWidth: 0,            // 值域边框线宽,单位px,默认为0(无边框)
            padding: 5,                // 值域内边距,单位px,默认各方向内边距为5,
                                       // 接受数组分别设定上右下左边距,同css
            itemGap: 10,               // 各个item之间的间隔,单位px,默认为10,
                                       // 横向布局时为水平间隔,纵向布局时为纵向间隔
            itemWidth: 20,             // 值域图形宽度,线性渐变水平布局宽度为该值 * 10
            itemHeight: 14,            // 值域图形高度,线性渐变垂直布局高度为该值 * 10
            splitNumber: 5,            // 分割段数,默认为5,为0时为线性渐变
            color:['#1e90ff','#f0ffff'],//颜色
            //text:['高','低'],         // 文本,默认为数值文本
            textStyle: {
                color: '#333'          // 值域文字颜色
            }
        },

        toolbox: {
            orient: 'horizontal',      // 布局方式,默认为水平布局,可选为:
                                       // 'horizontal' ¦ 'vertical'
            x: 'right',                // 水平安放位置,默认为全图右对齐,可选为:
                                       // 'center' ¦ 'left' ¦ 'right'
                                       // ¦ {number}(x坐标,单位px)
            y: 'top',                  // 垂直安放位置,默认为全图顶端,可选为:
                                       // 'top' ¦ 'bottom' ¦ 'center'
                                       // ¦ {number}(y坐标,单位px)
            color : ['#1e90ff','#22bb22','#4b0082','#d2691e'],
            backgroundColor: 'rgba(0,0,0,0)', // 工具箱背景颜色
            borderColor: '#ccc',       // 工具箱边框颜色
            borderWidth: 0,            // 工具箱边框线宽,单位px,默认为0(无边框)
            padding: 5,                // 工具箱内边距,单位px,默认各方向内边距为5,
                                       // 接受数组分别设定上右下左边距,同css
            itemGap: 10,               // 各个item之间的间隔,单位px,默认为10,
                                       // 横向布局时为水平间隔,纵向布局时为纵向间隔
            itemSize: 16,              // 工具箱图形宽度
            featureImageIcon : {},     // 自定义图片icon
            featureTitle : {
                mark : '辅助线开关',
                markUndo : '删除辅助线',
                markClear : '清空辅助线',
                dataZoom : '区域缩放',
                dataZoomReset : '区域缩放后退',
                dataView : '数据视图',
                lineChart : '折线图切换',
                barChart : '柱形图切换',
                restore : '还原',
                saveAsImage : '保存为图片'
            }
        },

        // 提示框
        tooltip: {
            trigger: 'item',           // 触发类型,默认数据触发,见下图,可选为:'item' ¦ 'axis'
            showDelay: 20,             // 显示延迟,添加显示延迟可以避免频繁切换,单位ms
            hideDelay: 100,            // 隐藏延迟,单位ms
            transitionDuration : 0.4,  // 动画变换时间,单位s
            backgroundColor: 'rgba(0,0,0,0.7)',     // 提示背景颜色,默认为透明度为0.7的黑色
            borderColor: '#333',       // 提示边框颜色
            borderRadius: 4,           // 提示边框圆角,单位px,默认为4
            borderWidth: 0,            // 提示边框线宽,单位px,默认为0(无边框)
            padding: 5,                // 提示内边距,单位px,默认各方向内边距为5,
                                       // 接受数组分别设定上右下左边距,同css
            axisPointer : {            // 坐标轴指示器,坐标轴触发有效
                type : 'line',         // 默认为直线,可选为:'line' | 'shadow'
                lineStyle : {          // 直线指示器样式设置
                    color: '#48b',
                    width: 2,
                    type: 'solid'
                },
                shadowStyle : {                       // 阴影指示器样式设置
                    width: 'auto',                   // 阴影大小
                    color: 'rgba(150,150,150,0.3)'  // 阴影颜色
                }
            },
            textStyle: {
                color: '#fff'
            }
        },

        // 区域缩放控制器
        dataZoom: {
            orient: 'horizontal',      // 布局方式,默认为水平布局,可选为:
                                       // 'horizontal' ¦ 'vertical'
            // x: {number},            // 水平安放位置,默认为根据grid参数适配,可选为:
                                       // {number}(x坐标,单位px)
            // y: {number},            // 垂直安放位置,默认为根据grid参数适配,可选为:
                                       // {number}(y坐标,单位px)
            // width: {number},        // 指定宽度,横向布局时默认为根据grid参数适配
            // height: {number},       // 指定高度,纵向布局时默认为根据grid参数适配
            backgroundColor: 'rgba(0,0,0,0)',       // 背景颜色
            dataBackgroundColor: '#eee',            // 数据背景颜色
            fillerColor: 'rgba(144,197,237,0.2)',   // 填充颜色
            handleColor: 'rgba(70,130,180,0.8)'     // 手柄颜色
        },

        // 网格
        grid: {
            x: 80,
            y: 60,
            x2: 80,
            y2: 60,
            // width: {totalWidth} - x - x2,
            // height: {totalHeight} - y - y2,
            backgroundColor: 'rgba(0,0,0,0)',
            borderWidth: 1,
            borderColor: '#ccc'
        },

        // 类目轴
        categoryAxis: {
            position: 'bottom',    // 位置
            nameLocation: 'end',   // 坐标轴名字位置,支持'start' | 'end'
            boundaryGap: true,     // 类目起始和结束两端空白策略
            axisLine: {            // 坐标轴线
                show: true,        // 默认显示,属性show控制显示与否
                lineStyle: {       // 属性lineStyle控制线条样式
                    color: '#48b',
                    width: 2,
                    type: 'solid'
                }
            },
            axisTick: {            // 坐标轴小标记
                show: true,       // 属性show控制显示与否,默认不显示
                interval: 'auto',
                // onGap: null,
                inside : false,    // 控制小标记是否在grid里
                length :5,         // 属性length控制线长
                lineStyle: {       // 属性lineStyle控制线条样式
                    color: '#333',
                    width: 1
                }
            },
            axisLabel: {           // 坐标轴文本标签,详见axis.axisLabel
                show: true,
                interval: 'auto',
                rotate: 0,
                margin: 8,
                // formatter: null,
                textStyle: {       // 其余属性默认使用全局文本样式,详见TEXTSTYLE
                    color: '#333'
                }
            },
            splitLine: {           // 分隔线
                show: true,        // 默认显示,属性show控制显示与否
                // onGap: null,
                lineStyle: {       // 属性lineStyle(详见lineStyle)控制线条样式
                    color: ['#ccc'],
                    width: 1,
                    type: 'solid'
                }
            },
            splitArea: {           // 分隔区域
                show: false,       // 默认不显示,属性show控制显示与否
                // onGap: null,
                areaStyle: {       // 属性areaStyle(详见areaStyle)控制区域样式
                    color: ['rgba(250,250,250,0.3)','rgba(200,200,200,0.3)']
                }
            }
        },

        // 数值型坐标轴默认参数
        valueAxis: {
            position: 'left',      // 位置
            nameLocation: 'end',   // 坐标轴名字位置,支持'start' | 'end'
            nameTextStyle: {},     // 坐标轴文字样式,默认取全局样式
            boundaryGap: [0, 0],   // 数值起始和结束两端空白策略
            splitNumber: 5,        // 分割段数,默认为5
            axisLine: {            // 坐标轴线
                show: true,        // 默认显示,属性show控制显示与否
                lineStyle: {       // 属性lineStyle控制线条样式
                    color: '#48b',
                    width: 2,
                    type: 'solid'
                }
            },
            axisTick: {            // 坐标轴小标记
                show: false,       // 属性show控制显示与否,默认不显示
                inside : false,    // 控制小标记是否在grid里
                length :5,         // 属性length控制线长
                lineStyle: {       // 属性lineStyle控制线条样式
                    color: '#333',
                    width: 1
                }
            },
            axisLabel: {           // 坐标轴文本标签,详见axis.axisLabel
                show: true,
                rotate: 0,
                margin: 8,
                // formatter: null,
                textStyle: {       // 其余属性默认使用全局文本样式,详见TEXTSTYLE
                    color: '#333'
                }
            },
            splitLine: {           // 分隔线
                show: true,        // 默认显示,属性show控制显示与否
                lineStyle: {       // 属性lineStyle(详见lineStyle)控制线条样式
                    color: ['#ccc'],
                    width: 1,
                    type: 'solid'
                }
            },
            splitArea: {           // 分隔区域
                show: false,       // 默认不显示,属性show控制显示与否
                areaStyle: {       // 属性areaStyle(详见areaStyle)控制区域样式
                    color: ['rgba(250,250,250,0.3)','rgba(200,200,200,0.3)']
                }
            }
        },

        polar : {
            center : ['50%', '50%'],    // 默认全局居中
            radius : '75%',
            startAngle : 90,
            splitNumber : 5,
            name : {
                show: true,
                textStyle: {       // 其余属性默认使用全局文本样式,详见TEXTSTYLE
                    color: '#333'
                }
            },
            axisLine: {            // 坐标轴线
                show: true,        // 默认显示,属性show控制显示与否
                lineStyle: {       // 属性lineStyle控制线条样式
                    color: '#ccc',
                    width: 1,
                    type: 'solid'
                }
            },
            axisLabel: {           // 坐标轴文本标签,详见axis.axisLabel
                show: false,
                textStyle: {       // 其余属性默认使用全局文本样式,详见TEXTSTYLE
                    color: '#333'
                }
            },
            splitArea : {
                show : true,
                areaStyle : {
                    color: ['rgba(250,250,250,0.3)','rgba(200,200,200,0.3)']
                }
            },
            splitLine : {
                show : true,
                lineStyle : {
                    width : 1,
                    color : '#ccc'
                }
            }
        },

        // 柱形图默认参数
        bar: {
            barMinHeight: 0,          // 最小高度改为0
            // barWidth: null,        // 默认自适应
            barGap: '30%',            // 柱间距离,默认为柱形宽度的30%,可设固定值
            barCategoryGap : '20%',   // 类目间柱形距离,默认为类目间距的20%,可设固定值
            itemStyle: {
                normal: {
                    // color: '各异',
                    barBorderColor: '#fff',       // 柱条边线
                    barBorderRadius: 0,           // 柱条边线圆角,单位px,默认为0
                    barBorderWidth: 1,            // 柱条边线线宽,单位px,默认为1
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                },
                emphasis: {
                    // color: '各异',
                    barBorderColor: 'rgba(0,0,0,0)',   // 柱条边线
                    barBorderRadius: 0,                // 柱条边线圆角,单位px,默认为0
                    barBorderWidth: 1,                 // 柱条边线线宽,单位px,默认为1
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                }
            }
        },

        // 折线图默认参数
        line: {
            itemStyle: {
                normal: {
                    // color: 各异,
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    lineStyle: {
                        width: 2,
                        type: 'solid',
                        shadowColor : 'rgba(0,0,0,0)', //默认透明
                        shadowBlur: 5,
                        shadowOffsetX: 3,
                        shadowOffsetY: 3
                    }
                },
                emphasis: {
                    // color: 各异,
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                }
            },
            //smooth : false,
            //symbol: null,         // 拐点图形类型
            symbolSize: 2,          // 拐点图形大小
            //symbolRotate : null,  // 拐点图形旋转控制
            showAllSymbol: false    // 标志图形默认只有主轴显示(随主轴标签间隔隐藏策略)
        },

        // K线图默认参数
        k: {
            // barWidth : null          // 默认自适应
            // barMaxWidth : null       // 默认自适应
            itemStyle: {
                normal: {
                    color: '#fff',          // 阳线填充颜色
                    color0: '#00aa11',      // 阴线填充颜色
                    lineStyle: {
                        width: 1,
                        color: '#ff3200',   // 阳线边框颜色
                        color0: '#00aa11'   // 阴线边框颜色
                    }
                },
                emphasis: {
                    // color: 各异,
                    // color0: 各异
                }
            }
        },

        // 散点图默认参数
        scatter: {
            //symbol: null,      // 图形类型
            symbolSize: 4,       // 图形大小,半宽(半径)参数,当图形为方向或菱形则总宽度为symbolSize * 2
            //symbolRotate : null,  // 图形旋转控制
            large: false,        // 大规模散点图
            largeThreshold: 2000,// 大规模阀值,large为true且数据量>largeThreshold才启用大规模模式
            itemStyle: {
                normal: {
                    // color: 各异,
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                },
                emphasis: {
                    // color: '各异'
                    label: {
                        show: false
                        // position: 默认自适应,水平布局为'top',垂直布局为'right',可选为
                        //           'inside'|'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                }
            }
        },

        // 雷达图默认参数
        radar : {
            itemStyle: {
                normal: {
                    // color: 各异,
                    label: {
                        show: false
                    },
                    lineStyle: {
                        width: 2,
                        type: 'solid'
                    }
                },
                emphasis: {
                    // color: 各异,
                    label: {
                        show: false
                    }
                }
            },
            //symbol: null,         // 拐点图形类型
            symbolSize: 2           // 可计算特性参数,空数据拖拽提示图形大小
            //symbolRotate : null,  // 图形旋转控制
        },

        // 饼图默认参数
        pie: {
            center : ['50%', '50%'],    // 默认全局居中
            radius : [0, '75%'],
            clockWise : false,          // 默认逆时针
            startAngle: 90,
            minAngle: 0,                // 最小角度改为0
            selectedOffset: 10,         // 选中是扇区偏移量
            itemStyle: {
                normal: {
                    // color: 各异,
                    borderColor: '#fff',
                    borderWidth: 1,
                    label: {
                        show: true,
                        position: 'outer'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    labelLine: {
                        show: true,
                        length: 20,
                        lineStyle: {
                            // color: 各异,
                            width: 1,
                            type: 'solid'
                        }
                    }
                },
                emphasis: {
                    // color: 各异,
                    borderColor: 'rgba(0,0,0,0)',
                    borderWidth: 1,
                    label: {
                        show: false
                        // position: 'outer'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    labelLine: {
                        show: false,
                        length: 20,
                        lineStyle: {
                            // color: 各异,
                            width: 1,
                            type: 'solid'
                        }
                    }
                }
            }
        },

        map: {
            mapType: 'china',   // 各省的mapType暂时都用中文
            mapLocation: {
                x : 'center',
                y : 'center'
                // width    // 自适应
                // height   // 自适应
            },
            showLegendSymbol : true,       // 显示图例颜色标识(系列标识的小圆点),存在legend时生效
            itemStyle: {
                normal: {
                    // color: 各异,
                    borderColor: '#fff',
                    borderWidth: 1,
                    areaStyle: {
                        color: '#ccc'//rgba(135,206,250,0.8)
                    },
                    label: {
                        show: false,
                        textStyle: {
                            color: 'rgba(139,69,19,1)'
                        }
                    }
                },
                emphasis: {                 // 也是选中样式
                    // color: 各异,
                    borderColor: 'rgba(0,0,0,0)',
                    borderWidth: 1,
                    areaStyle: {
                        color: 'rgba(255,215,0,0.8)'
                    },
                    label: {
                        show: false,
                        textStyle: {
                            color: 'rgba(139,69,19,1)'
                        }
                    }
                }
            }
        },

        force : {
            // 数据map到圆的半径的最小值和最大值
            minRadius : 10,
            maxRadius : 20,
            density : 1.0,
            attractiveness : 1.0,
            // 初始化的随机大小位置
            initSize : 300,
            // 向心力因子,越大向心力越大
            centripetal : 1,
            // 冷却因子
            coolDown : 0.99,
            // 分类里如果有样式会覆盖节点默认样式
            itemStyle: {
                normal: {
                    // color: 各异,
                    label: {
                        show: false
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    nodeStyle : {
                        brushType : 'both',
                        color : '#f08c2e',
                        strokeColor : '#5182ab'
                    },
                    linkStyle : {
                        strokeColor : '#5182ab'
                    }
                },
                emphasis: {
                    // color: 各异,
                    label: {
                        show: false
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    nodeStyle : {},
                    linkStyle : {}
                }
            }
        },

        chord : {
            radius : ['65%', '75%'],
            center : ['50%', '50%'],
            padding : 2,
            sort : 'none', // can be 'none', 'ascending', 'descending'
            sortSub : 'none', // can be 'none', 'ascending', 'descending'
            startAngle : 90,
            clockWise : false,
            showScale : false,
            showScaleText : false,
            itemStyle : {
                normal : {
                    label : {
                        show : true
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    lineStyle : {
                        width : 0,
                        color : '#000'
                    },
                    chordStyle : {
                        lineStyle : {
                            width : 1,
                            color : '#666'
                        }
                    }
                },
                emphasis : {
                    lineStyle : {
                        width : 0,
                        color : '#000'
                    },
                    chordStyle : {
                        lineStyle : {
                            width : 2,
                            color : '#333'
                        }
                    }
                }
            }
        },

        island: {
            r: 15,
            calculateStep: 0.1  // 滚轮可计算步长 0.1 = 10%
        },

        markPoint : {
            symbol: 'pin',         // 标注类型
            symbolSize: 10,        // 标注大小,半宽(半径)参数,当图形为方向或菱形则总宽度为symbolSize * 2
            //symbolRotate : null, // 标注旋转控制
            itemStyle: {
                normal: {
                    // color: 各异,
                    // borderColor: 各异,     // 标注边线颜色,优先于color
                    borderWidth: 2,            // 标注边线线宽,单位px,默认为1
                    label: {
                        show: true,
                        position: 'inside' // 可选为'left'|'right'|'top'|'bottom'
                        // textStyle: null      // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                },
                emphasis: {
                    // color: 各异
                    label: {
                        show: true
                        // position: 'inside'  // 'left'|'right'|'top'|'bottom'
                        // textStyle: null     // 默认使用全局文本样式,详见TEXTSTYLE
                    }
                }
            }
        },

        markLine : {
            // 标线起始和结束的symbol介绍类型,如果都一样,可以直接传string
            symbol: ['circle', 'arrow'],
            // 标线起始和结束的symbol大小,半宽(半径)参数,当图形为方向或菱形则总宽度为symbolSize * 2
            symbolSize: [2, 4],
            // 标线起始和结束的symbol旋转控制
            //symbolRotate : null,
            itemStyle: {
                normal: {
                    // color: 各异,           // 标线主色,线色,symbol主色
                    // borderColor: 随color,     // 标线symbol边框颜色,优先于color
                    borderWidth: 2,          // 标线symbol边框线宽,单位px,默认为2
                    label: {
                        show: false,
                        // 可选为 'start'|'end'|'left'|'right'|'top'|'bottom'
                        position: 'inside',
                        textStyle: {         // 默认使用全局文本样式,详见TEXTSTYLE
                            color: '#333'
                        }
                    },
                    lineStyle: {
                        // color: 随borderColor, // 主色,线色,优先级高于borderColor和color
                        // width: 随borderWidth, // 优先于borderWidth
                        type: 'solid',
                        shadowColor : 'rgba(0,0,0,0)', //默认透明
                        shadowBlur: 5,
                        shadowOffsetX: 3,
                        shadowOffsetY: 3
                    }
                },
                emphasis: {
                    // color: 各异
                    label: {
                        show: false
                        // position: 'inside' // 'left'|'right'|'top'|'bottom'
                        // textStyle: null    // 默认使用全局文本样式,详见TEXTSTYLE
                    },
                    lineStyle : {}
                }
            }
        },

        textStyle: {
            decoration: 'none',
            fontFamily: 'Arial, Verdana, sans-serif',
            fontFamily2: '微软雅黑',    // IE8- 字体模糊并且不支持不同字体混排,额外指定一份
            fontSize: 12,
            fontStyle: 'normal',
            fontWeight: 'normal'
        },

        // 默认标志图形类型列表
        symbolList : [
          'circle', 'rectangle', 'triangle', 'diamond',
          'emptyCircle', 'emptyRectangle', 'emptyTriangle', 'emptyDiamond'
        ],
        loadingText : 'Loading...',
        // 可计算特性配置,孤岛,提示颜色
        calculable: false,              // 默认关闭可计算特性
        calculableColor: 'rgba(255,165,0,0.6)',       // 拖拽提示边框颜色
        calculableHolderColor: '#ccc', // 可计算占位提示颜色
        nameConnector: ' & ',
        valueConnector: ' : ',
        animation: true,
        animationThreshold: 2500,       // 动画元素阀值,产生的图形原素超过2500不出动画
        addDataAnimation: true,         // 动态数据接口是否开启动画效果
        animationDuration: 2000,
        animationEasing: 'ExponentialOut'    //BounceOut
    }


    文章评论

    评论列表(0
